NOGA Carmex Solid Carbide Mini Mill Thread Shank Diameter 3 x M1.6 x 0.35 x Neck Length 4.8 M03012C5 0.35ISO 1 pc

Catalog number: M03012C5 0.35ISO Features: ●High-speed cutting reduces machining time. ●Short blade length (3 teeth) does not put a burden on cutting. ●Effective threads can be cut to the corners of blind holes. ●Thread cutting can be performed on difficult-to-cut materials and high-hardness materials up to about HRC45. Applications: ●Cutting materials: difficult-to-cut materials and high-hardness materials up to about HRC45. ●For thread cutting of precision machine parts and electrical parts. Specifications: ●Nominal size: M1.6 ●Pitch (mm): 0.35 ●Blade diameter (mm): 1.20 ●Total length (mm): 39 ●Number of blades (pieces): 3 ●Shank diameter (mm): 3 ●Neck length (mm): 4.8 ●Surface treatment: Aluminum titanium nitride (TiAlN) multi-layer coating (MT7) ●Thread depth: Up to 3 times the blade diameter ●Thread: For ISO metric threads Material/Finish: ●Ultra-fine grain carbide
