OMRON Power Relay LY2N DC24 1 piece

Catalog number: LY2N DC24 Features: ● Uses Bush-in Plus terminal sockets that reduce wiring labor with light insertion force and strong pull-out strength. ● International standards UL, CSA, SEV certified products and Electrical Appliance and Material Safety Law compliant products are standard. ● Equipped with an arc barrier to block arcs. ● Meets 2000V withstand voltage. ● Diode built-in type and CR built-in circuit type have been added to the series. ● International standards LR and VDE certified types are also available. Applications: ● For power switching control (2 contacts). Specifications: ● Contact configuration: 2C ● Rated voltage (V): DC24 ● Contact rating: Resistive load AC 110V 10A, DC 24V 10A ● Meets 2000V withstand voltage ● International standards UL, CSA, SEV certified products and Electrical Appliance and Material Safety Law compliant products are standard equipment
