Catalog number: HT3-S-M1.4X0.3 Features: ● A general tap that is used in a wide range of applications. ● Can be used for both through holes and blind holes. Applications: ● Workpiece: Medium carbon steel, aluminum alloy, etc. Specifications: ● Tip: Top ● Precision: JIS Class 3 ● Nominal dimensions: M1.4 ● Pitch (mm): 0.3 ● Thread length (mm): 11 ● Total length (mm): 34 ● Shank diameter (mm): 3 ● Shank square section (mm): 2.5 ● Pilot hole diameter (mm): 1.1 ● Machined thread: Metric thread ● Surface treatment: Non-coated Material/Finish: ● Alloy tool steel (SKS)
