OSG Carbide End Mill FX Multi-Blade Corner R Long 12XR3 8523913 FX-CR-MG-EML-12XR3 1 piece

Catalog number: FX-CR-MG-EML-12XR3 Features: ●Long shank type that can process deep parts. ●Can also be used to prevent corner chipping. Applications: ●Cutting materials: carbon steel, alloy steel, tool steel (up to 40HRC), pre-hardened steel, hardened steel (up to 45HRC), cast iron, ductile cast iron (up to 350HB). Specifications: ●Blade diameter (mm): 12 ●Corner radius (mm): 3 ●Blade length (mm): 40 ●Total length (mm): 110 ●Shank diameter (mm): 12 ●Number of blades (pieces): 4 ●Surface treatment: FX coating ●Number of blades: 4 ●Twist angle 30° Material/Finish: ●Carbide
