OSG Carbide End Mill FX 2-Blade Long 4 8522040 FX-MG-EDL-4 1 piece

Catalog number: FX-MG-EDL-4 Features: ● General-purpose 2-blade end mill long blade type with FX coating that has excellent heat resistance. Applications: ● Workpiece: Carbon steel, alloy steel, tool steel (up to 40HRC), pre-hardened steel (up to 45HRC), hardened steel (up to 45HRC), cast iron, ductile cast iron (up to 350HB). Specifications: ● Blade diameter (mm): 4 ● Blade length (mm): 17 ● Shank diameter (mm): 6 ● Total length (mm): 50 ● Surface treatment: FX coating ● Twist angle 30° ● Center cut: Included Material/Finish: ● Carbide
