OSG Carbide Ball End Mill Phoenix Pencil Neck Deep Feeder Ball Ball Radius 2mm Blade Length 6mm Neck Length 50mm 3095443 PHX-PC-DBT-R2X1X50 ​​1 piece

Catalog number: PHX-PC-DBT-R2X1X50 ​​Features: ●Realizes high-efficiency machining that changes the conventional wisdom of deep engraving. Applications: ●Cutting materials: carbon steel, alloy steel, tool steel (up to 40HRC), pre-hardened steel (up to 60HRC), stainless steel (up to 35HRC), cast iron, ductile cast iron (up to 350HB). Specifications: ●Ball radius (mm): 2 ●Neck length (mm): 50 ●Blade length (mm): 6 ●Total length (mm): 100 ●Shank diameter (mm): 6 ●Number of blades (pieces): 3 ●Surface treatment: WXS coating ●Number of blades: 3 ●Twist angle 45° Material/Finish: ●Carbide
