OSG Carbide Ball End Mill Phoenix Pencil Neck Deep Feeder Ball Ball Radius 2.5mm Blade Length 7.5mm Neck Length 35mm 3095541 PHX-PC-DBT-R2.5X1 X35 1 piece

Catalog number: PHX-PC-DBT-R2.5X1 X35 Features: ●Realizes high-efficiency machining that changes the conventional wisdom of deep engraving. Applications: ●Cutting materials: carbon steel, alloy steel, tool steel (up to 40HRC), pre-hardened steel (up to 60HRC), stainless steel (up to 35HRC), cast iron, ductile cast iron (up to 350HB). Specifications: ●Ball radius (mm): 2.5 ●Neck length (mm): 35 ●Blade length (mm): 7.5 ●Total length (mm): 100 ●Shank diameter (mm): 8 ●Number of blades (pieces): 3 ●Surface treatment: WXS coating ●Number of blades: 3 ●Twist angle 45° Material/Finish: ●Carbide
