OSG Carbide Ball End Mill Phoenix Pencil Neck Deep Feeder Ball Ball Radius 4mm Blade Length 12mm Neck Length 82.4mm 3095853 PHX-PC-DBT-R4X1.5 X82.4 1 piece

Catalog number: PHX-PC-DBT-R4X1.5 X82.4 Features: ●Realizes high-efficiency machining that changes the conventional wisdom of deep engraving. Applications: ●Cutting materials: carbon steel, alloy steel, tool steel (up to 40HRC), pre-hardened steel (up to 60HRC), stainless steel (up to 35HRC), cast iron, ductile cast iron (up to 350HB). Specifications: ●Ball radius (mm): 4 ●Neck length (mm): 82.4 ●Blade length (mm): 12 ●Total length (mm): 150 ●Shank diameter (mm): 12 ●Number of blades (pieces): 3 ●Surface treatment: WXS coating ●Number of blades: 3 ●Twist angle 45° Material/Finish: ●Carbide
