OSG Carbide Ball End Mill Phoenix Pencil Neck Deep Feeder Ball Ball Radius 5mm Blade Length 15mm Neck Length 120mm 3096044 PHX-PC-DBT-R5X1X120 1 piece

Catalog number: PHX-PC-DBT-R5X1X120 Features: ●Realizes high-efficiency machining that changes the conventional wisdom of deep engraving. Applications: ●Cutting materials: carbon steel, alloy steel, tool steel (up to 40HRC), pre-hardened steel (up to 60HRC), stainless steel (up to 35HRC), cast iron, ductile cast iron (up to 350HB). Specifications: ●Ball radius (mm): 5 ●Neck length (mm): 120 ●Blade length (mm): 15 ●Total length (mm): 180 ●Shank diameter (mm): 16 ●Number of teeth (pieces): 3 ●Surface treatment: WXS coating ●Number of teeth: 3 ●Twist angle 45° Material/Finish: ●Carbide
