OSG Carbide Ball End Mill Phoenix Pencil Neck Deep Feeder Ball Ball Radius 5mm Blade Length 15mm Neck Length 92.9mm 3096064 PHX-PC-DBT-R5X2X9 2.9 1 piece

Catalog number: PHX-PC-DBT-R5X2X9 2.9 Features: ●Realizes high-efficiency machining that changes the conventional wisdom of deep engraving. Applications: ●Cutting materials: carbon steel, alloy steel, tool steel (up to 40HRC), pre-hardened steel (up to 60HRC), stainless steel (up to 35HRC), cast iron, ductile cast iron (up to 350HB). Specifications: ●Ball radius (mm): 5 ●Neck length (mm): 92.9 ●Blade length (mm): 15 ●Total length (mm): 160 ●Shank diameter (mm): 16 ●Number of blades (pieces): 3 ●Surface treatment: WXS coating ●Number of blades: 3 ●Twist angle 45° Material/Finish: ●Carbide
