オーエスジー（株）

OSG Carbide Ball End Mill Phoenix Pencil Neck Deep Feeder Ball Ball Radius 6mm Blade Length 18mm Neck Length 60mm 3096241 PHX-PC-DBT-R6X1X60 1 piece

OSG Carbide Ball End Mill Phoenix Pencil Neck Deep Feeder Ball Ball Radius 6mm Blade Length 18mm Neck Length 60mm 3096241 PHX-PC-DBT-R6X1X60 1 piece

JAN： 　
Carbide Ball End Mill Cutting Tools OSG Carbide End Mill A Turning and milling tools
¥53,196
¥53,196
Sale Sold out
Shipping calculated at checkout.
Catalog number: PHX-PC-DBT-R6X1X60 Features: ●Realizes high-efficiency machining that changes the conventional wisdom of deep engraving. Applications: ●Cutting materials: carbon steel, alloy steel, tool steel (up to 40HRC), pre-hardened steel (up to 60HRC), stainless steel (up to 35HRC), cast iron, ductile cast iron (up to 350HB). Specifications: ●Ball radius (mm): 6 ●Neck length (mm): 60 ●Blade length (mm): 18 ●Total length (mm): 120 ●Shank diameter (mm): 16 ●Number of teeth (pieces): 3 ●Surface treatment: WXS coating ●Number of teeth: 3 ●Twist angle 45° Material/Finish: ●Carbide
