OSG A-point tap STD M2X0.4 8325049 A-POT-STD-M2X0.4 1 piece

Catalog number: A-POT-STD-M2X0.4 Features: ● Stable chip removal and can be used with a wide range of work materials and machines. Applications: ● For through hole processing. ● Work materials: low, medium, and high carbon steel, alloy steel, tempered steel (25 to 45HRC), stainless steel, tool steel, cast steel, ductile cast iron, copper, brass, brass castings, bronze, rolled aluminum, aluminum alloy castings, magnesium alloy castings, zinc alloy castings, titanium alloys. Specifications: ● Precision: OH1.5 ● Precision notation: STD ● Nominal dimensions: M2 ● Pitch (mm): 0.4 ● Thread length (mm): 12 ● Total length (mm): 40 ● Shank diameter (mm): 3 ● Shank square section (mm): 2.5 ● Pilot hole diameter (mm): 1.6 ● Number of teeth: 5 teeth ● Machining thread: Metric thread ● Surface treatment: V coating Material/Finish: ● Powdered high speed steel (CPM)
