OSS Flat Precision Level (for general work) 250mm 201-250 1 pc

Catalog number: 201-250 Features: ● Suitable for leveling worktables, machine tools, etc. ● The main body is made of high-quality cast iron (FC250), and the flat and V-shaped bottom surfaces are precisely manufactured. ● There are two M5 tapped holes on the back of the main body, allowing it to be attached to a measurement pitch-adjustable base or any workpiece. ● An inspection report is included as standard. ● The bottom surface is finished with a V-shaped surface, so it can be placed on a steel pipe to check the level. Applications: ● As a standard for level inspection and leveling. Specifications: ● Length (mm): 250 ● Width (mm): 44 ● Thickness (mm): 45 ● Sensitivity (mm): 0.02 ● Precision: Scale error of main bubble tube within ±0.7 scales ● Flatness of bottom surface: within 0.003 mm Material/Finish: ● Cast iron
