Catalog number: EZ7412S-B Features: *Small, light, and easy to use, palm-sized. *Equipped with an LED light, making it convenient to use in dark places. *Equipped with a push switch with independent forward and reverse directions. *Equipped with a charging status indicator lamp. (Charging: Red, Charging complete: Green) *Equipped with overcharge, overdischarge, and overcurrent protection circuits to protect the battery and motor. Applications: *For tightening and loosening small screws. Specifications: ● Maximum tightening torque (N・m): 1 ● Color: Black ● No-load rotation speed (min［［の−１力］］): 230 ● Voltage (V): 3.7 ● Tightening torque: 1N･m (rigid body tightening torque when using electric) 8N･m (maximum durability torque when tightening by hand) ● Work guide (small screw without spring washer): Approximately 620 pieces (M3×5mm), approximately 540 pieces (M5×10mm) ● No-load rotation speed (rpm): 230 ● Lithium-ion battery 3.7V 850mAh (built-in battery) ● USB rechargeable (USB TypeA-microUSB TypeB) ● Screw tightening work range: Small screw M3 (when using electric), small screw M6 (when tightening by hand) ● Total length of main body: 128mm ● 6.35 hexagonal shaft One-touch bit lock method (dimensions up to step 9, 11.5, 13mm) ● USB terminal 1 terminal microUSB TypeB DC5V ● Charging time Approximately 45 minutes (when using our EZ37C4 or EZ37C5), approximately 35 minutes (when using a commercially available USB charger at 5V 1A), approximately 25 minutes (when using a commercially available USB charger at 5V 2A) Set contents/accessories: ● 1 x 5-piece bit set ● 1 x USB charging cable (adapter not included, please use a commercially available USB 5V adapter) Note: ● *Not suitable for drilling work
