Catalog number: DNF18-205FIB-L Features: ●A fully insulated nylon disconnect, eliminating the need for insulating covers such as sleeves. ●A wire stopper is provided inside the barrel, allowing the wire to be inserted to the correct position. Applications: ●Interlocking of copper wires. Specifications: ●Wire clamping range Stranded wire (mm2): 0.5-1.0 ●Wire clamping range AWG: 22-18 ●Color: Red ●Total length (mm): 19.8 ●Rated voltage (V): 600 ●Maximum insulation outer diameter: 3.5mm ●Tab size (mm): .205/.187 x .03 ●Maximum operating temperature: 105°C (indoors) ●UL310 certified Material/Finish: ●Brass ●Tin plated ●Nylon 66
