PANDUIT Crimp Terminal, Plug-in Type, Fully Insulated, Female Type, AWG16-14, Blue (100 Pieces) DNF14-206FIB-C 1 Bag

Catalog number: DNF14-206FIB-C Features: ●A fully insulated nylon disconnect, eliminating the need for insulating covers such as sleeves. ●A wire stopper is provided inside the barrel, allowing the wire to be inserted to the correct position. Applications: ●Interlocking of copper wires. Specifications: ●Wire clamping range Stranded wire (mm2): 1.5-2.5 ●Wire clamping range AWG: 16-14 ●Color: Blue ●Total length (mm): 19.8 ●Rated voltage (V): 600 ●Maximum insulation outer diameter: 4.1mm ●Tab size (mm): .205/.187 x .02 ●Maximum operating temperature: 105°C (indoors) ●Tab size (mm): 5.2/4.75 x 0.5 ●UL310 certified Material/Finish: ●Brass ●Tin plated ●Nylon 66
