Parker Industrial Hose Global Core Hose Parallel Thread Union for Pipes on Both Ends (with Male Sheet) Operating Pressure 35.0 MPa Allowable Bending Radius 50 mm or More F431GUGU040404-100CM 1 Piece

Catalog number: F431GUGU040404-100CM Features: *Please note that this product will be shipped at a later date due to the hose being cut and both ends being crimped. *Please refrain from returning this product due to the processing involved. *This hose has a pressure range of 2000 to 5000 psi (13.8 to 34.5 MPa). Applications: *For machine tools and other hydraulic equipment in general. Specifications: ●Outer diameter (mm): 13.0 ●Inner diameter (mm): 6.3 ●Operating pressure (MPa): 35.0 ●Allowable bending radius (mm or more): 50 ●Inner diameter of hose (inch): 1/4 ●Length (m): 130 ●Dash designation: 4 ●Operating temperature range (℃): -40 to +125 ●Fittings part number: 1GU43-4-4 ●Hose: ISO18752 standard (pressure standard) and SAE standard (structural standard) ●Compatible fluids: petroleum-based hydraulic fluids and lubricants ●Length: 1m ●Standard type Material/Finish: ●Synthetic rubber Note: ●As the hose is cut and both ends are crimped, returns are not accepted. ●Please check the size before ordering.
