PISCO silencer, taper male thread type for pipes, SR01, 1 piece

Catalogue number: SR01 Features: ●Excellent sound-proofing effect. ●Long life. Specifications: ●Volume reduction (dB): 25 ●Effective cross-sectional area (mm2): 12 ●Connection diameter: G1/8B (mounting screw size Rc1/8) ●Total length (mm): 28.2 ●Operating pressure (MPa): 0.9 ●Operating temperature (℃): 0 to 60 (no freezing) ●Operating fluid: Air ●Outer diameter (mm): 15.5 ●Operating pressure: 0.9MPa ●Operating temperature range: 0 to 60℃ (no freezing) Material/Finish: ●Plastic parts: Polybutylene terephthalate (PBT) ●Element: Polyvinyl formal (PVF)
