PISCO silencer, taper male thread type for pipes, SR03, 1 piece
PISCO silencer, taper male thread type for pipes, SR03, 1 piece
Regular price
¥496
Regular price
Sale price
¥496
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Catalogue number: SR03 Features: ●Excellent sound-proofing effect. ●Long life. Specifications: ●Volume reduction (dB): 20 ●Effective cross-sectional area (mm2): 62 ●Connection diameter: G3/8B (mounting screw size Rc3/8) ●Total length (mm): 58.0 ●Operating pressure (MPa): 0.9 ●Operating temperature (℃): 0 to 60 (no freezing) ●Operating fluid: Air ●Outer diameter (mm): 26.0 ●Operating pressure: 0.9MPa ●Operating temperature range: 0 to 60℃ (no freezing) Material/Finish: ●Plastic parts: Polybutylene terephthalate (PBT) ●Element: Polyvinyl formal (PVF)
