PISCO Throttle Valve Elbow Tube 10mm Thread R1/4 JNC10-02 1 pc

Catalog number: JNC10-02 Features: ●Can control the speed of pneumatic equipment and pneumatic signals. ●Can adjust the flow rate while air is flowing. Specifications: ●Applicable tube outer diameter D (mm): 10 ●Connection port size: R1/4 ●Operating temperature (℃): 0 to 60 (no freezing) ●Operating fluid: Air ●Operating pressure (MPa): -0.1 to 0.9 ●Operating temperature range: 0 to 60℃ (no freezing) ●Operating pressure: 0.9MPa ●Operating vacuum pressure: -100kPa Materials/Finish: ●Metal parts: Brass + electroless nickel plating ●Resin parts: Polybutylene terephthalate (PBT) ●Seal rubber: Nitrile rubber (NBR)
