PISCO Throttle Valve Union Straight JNMU12 1 pc
PISCO Throttle Valve Union Straight JNMU12 1 pc
Regular price
¥1,246
Regular price
Sale price
¥1,246
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Catalogue number: JNMU12 Features: ● Controls the speed of pneumatic equipment and air pressure signals. ● Flow rate can be adjusted while air is flowing. Specifications: ● Applicable tube outer diameter D (mm): 12 x 12 ● Operating temperature (℃): 0 to 60 (no freezing) ● Fluid used: Air ● Operating pressure (MPa): -0.1 to 1 ● Operating pressure: 1.0 MPa ● Vacuum pressure used: -100 kPa ● Operating temperature range: 0 to 60℃ (no freezing) Material/Finish: ● Metal parts: Brass + electroless nickel plating ● Plastic parts: Polybutylene terephthalate (PBT) ● Sealing rubber: Nitrile rubber (NBR)
