PISCO throttle valve, small union straight, PP type, PJNMU8, 1 piece

Catalog number: PJNMU8 Features: ●The main body is made of PP, which is suitable for clean environments. ●The oil-free specifications allow it to meet the needs of a wide range of fields. ●The metal material is SUS304, and the seal material is EPDM. Specifications: ●Applicable tube outer diameter D (mm): 8 x 8 ●Operating temperature (℃): 0 to 80 (no freezing) ●Operating fluid: air, water (conditions apply), other (conditions apply) ●Operating pressure (MPa): -0.1 to 1 ●Operating temperature range: 0 to 80℃ (no freezing) ●Maximum operating pressure: 1.0MPa (at 0 to 20℃) ●Operating vacuum pressure: -100kPa Materials/Finish: ●Metal parts: Stainless steel (SUS304) ●Resin parts: Polypropylene (PP) ●Seal rubber: Ethylene propylene rubber (EPDM) Caution: ●When using water or other chemicals as the fluid, be sure to observe the following conditions. 1. When using water or liquids, keep the surge pressure below the maximum operating pressure. 2. When using water or other liquids, we recommend using an insert ring. 3. Regarding chemicals, solvents, mixed gases, etc., our specifications may differ depending on the conditions of use, so please check before use.
