PISCO Main Block Air Extraction Port Universal Taper MHT12M6 1 pc

Catalog number: MHT12M6 Features: ● Assembled manifold for centralized distribution, etc. ● The same flow rate as steel pipe piping can be ensured, and the external dimensions are about half. Specifications: ● Hexagonal face (mm): Assembly screw section: 17, Tapered screw section: 12 ● Connection port size: M6 x 1 ● Maximum operating pressure (MPa): 1 ● Operating temperature range (℃): 0 to 60 (no freezing) ● Assembly screw size: M12 x 1 ● Fluid used: Air ● Operating temperature range: 0 to 60℃ (no freezing) ● Maximum operating pressure: 1MPa (0.9MPa when using coupling module QMC20) ● Operating vacuum pressure: -100kPa Materials/Finish: ● Body: Brass + electroless nickel plating + polybutylene terephthalate (PBT) ● Sealing rubber: Nitrile rubber (NBR)
