PISCO Vacuum Generator, Pipe Union Straight, Centralized Exhaust, VUH05-44J, 1 pc

Catalog number: VUH05-44J Features: ● Generates a vacuum from compressed air. ● Small and lightweight. Specifications: ● Applicable tube outer diameter D (mm): 4 x 4 ● Nozzle diameter (mm): 0.5 ● Fluid used: Air ● Fluid temperature (℃): 0 to 60 (no freezing) ● Operating pressure (MPa): 0.15 to 0.7 ● Exhaust port tube outer diameter EX: 6 ● Operating temperature range: 0 to 60℃ (no freezing) ● Operating pressure: 0.15 to 0.7MPa ● Rated supply pressure: 0.5MPa ● High vacuum type Materials/Finish: ● Metal parts: Brass + electroless nickel plating ● Plastic parts: Polybutylene terephthalate (PBT) ● Element: Polyvinyl formal (PVF)
