Catalogue number: NAR-815 Features: ●Portable automatic air reel. ●The hose can be wound up with one push of a button. ●Large-capacity air supply. (φ11 hose) ●Ideal for machine assembly and maintenance sites. Specifications: ●Inner diameter x outer diameter of hose (mm): 8.0 x 12.0 ●Total length of hose (m): 15 ●Primary side mounting: Rc1/4 ●Secondary side mounting: With socket ●Primary side total length of hose (m): 1 ●Secondary side total length of hose (m): 15 ●Maximum operating pressure (MPa): 1.5 ●Width (mm): 300 ●Depth (mm): 450 ●Height (mm): 450 ●Color: Orange ●Hose material: Polyurethane ●For stationary use only Material/Finish: ●Main body: Resin Set contents/Accessories: ●Primary side hose ASSY 1m (with hose fittings and plug)
