SANWA Analog Multi-Tester with Temperature Measurement SP20 1 unit

Catalog number: SP20 Features: ●Large scale. ●Temperature can be measured with a separately sold probe. ●Includes a battery check function for 1.5V batteries. ●Tilt stand makes it easy to see the meter's deflection. ●20 measurement ranges cover general applications. ●500μF capacitor check range Applications: ●Electrical work, equipment maintenance, home appliance repairs ●Electronics work Specifications: ● DC voltage (V): 500 ● AC voltage (V): 500 ● DC current (A): 0.25 ● Resistance (Ω): 2M ● Battery check: 2V range for 1.5V (RL = 20Ω) ● Calibration documents: Supported ● Power supply (V): 2 AA batteries (R6P) (monitor battery included) ● Width (mm): 99 ● Depth (mm): 41 ● Height (mm): 144 ● Power supply: 2 AA batteries (R6P) (monitor battery included) ● Capacitor capacity (F): 500μ ● DC high voltage (V): 25K ● Battery check: 1.5V ● Temperature (℃): 200 ● Width x Depth x Height: 99 x 41 x 144mm ● Power supply: 2 AA batteries (R6P) (monitor battery included) ● Comes with 1 spare fuse (F0305) ● Fuse specifications: Φ6.3 x 30mm 250V/0.5A/IR300A Glass tube (F0305) Set contents/accessories: ●Instruction manual ●Test lead TL-61 ●1 spare fuse (F0305) Caution: ●Do not use on power lines exceeding 6 kVA. ●Do not input signals that exceed the maximum rated input value. ●Do not use if the main unit or test leads are damaged. ●Do not hold the test pin side of the test lead beyond the flange during measurement. ●Do not switch to other functions or ranges, or change the plug during measurement.
