Catalog number: PM33A Features: ●Pocket-sized multimeter and clamp meter combination. ●The clamp is U-shaped, 7mm thick, with a clamp diameter of Φ10mm, and the angle can be changed from 0 to 180°. ●With a MIN/MAX value hold function. ●CE-certified product. ●Complies with international safety standard CAT.[3]300V ●With diode measurement/continuity buzzer function ●Capable of measuring capacitor capacitance up to 66mF from 6.6nF range ●Capable of measuring frequency up to 66kHz from 660Hz range ●Clamp current measurement up to 100A for DC and AC current ●20 to 80% duty ratio can be measured Applications: ●For equipment maintenance. ●For measuring current such as distribution boards. ●For electronic work. ●For building maintenance. ●For facility maintenance. Specifications: ● DC voltage (V): 600 ● AC voltage (V): 600 ● DC current (A): 100 ● AC current (A): 100 ● Resistance (Ω): 66M ● Detection method: Average value rectification (MEAN) ● Continuity check: Buzzer sounds when less than approximately 30Ω Open voltage: Approx. 1.2V●Calibration documents: Supported●Power supply (V): 2 AAA alkaline batteries (LR03) (included)●Width (mm): 75●Depth (mm): 19.9●Height (mm): 130●Power supply: 2 AAA alkaline batteries (LR03) (included)●Width (mm): 75●Depth (mm): 19.9●Height (mm): 130●Continuous use time (h): Approx. 66●Case: None●Capacitor: 66mF●Maximum display (counts): 6600●Diode test: Open voltage 1.2V●Duty ratio: 20-80%●Frequency (kHz): 66●Relative value measurement function●Auto power off function●Safety standards CAT. ［［Ｒ２］］600V CAT. ［［Ｒ３］］300V Set contents/accessories:●Instruction manual Caution:●Do not use on power lines exceeding 3.6 kVA.●The clamp sensor of this device is for low voltage use. Clamp current measurements should be used on lines of 600 V or less. ●During measurement, do not hold the test probe beyond the flange on the test pin side or beyond the barrier of the clamp sensor. ●Do not switch to other functions or ranges during measurement. ●Special waveforms such as those of inverter circuits may cause the device to malfunction or not measure correctly.
