SK Digital Scribing Gauge 300mm GDCS-300ST 1 unit

Catalog number: GDCS-300ST Features: * Compatible with the optional BluetoothBOX (DTW-DG01). * Stable marking work is possible on the base end surface. * Measurement values can be transmitted wirelessly to a PC. * Convenient for repeated marking work of a fixed size with high precision. * To ensure accuracy, an inspection sheet is included with values recorded at the time of inspection. * Pencil marking needle is included. * Equipped with a hold function. * Equipped with an auto-off function (approx. 20 minutes). Uses: ●As a marking gauge using the base end surface of the main scale with the base of the subscale as a reference Specifications: ●Manufacturer code: 151996 ●Measuring range (mm): 0-300 ●Minimum display (mm): 0.01 ●Depth bar: None ●Instrument error (mm): ±0.08 ●Power supply: CR2032 (included for testing) ●Power supply (V): CR2032 (included for testing) ●Base dimensions (mm): 100 ●Type: Digital ●Parallelism of base (mm): 0.08 Material/Finish: ●Body: Stainless steel Set contents/Accessories: ●PC case ●Pencil marking needle SC-P ●CR2032 Note: ●Instrument error does not include quantization error (±1 count).
