SK Screw Pin Gauge M5 x 0.8 THP-0508 1 piece

Catalogue number: THP-0508 Features: ●Easy centering of female threaded holes. ●By using two pieces, center pitch can be easily measured. ●Can be attached and detached in a short time using simple tools. ●Origin positioning using threaded holes, which was previously difficult, is now possible. ●Measurements can be made cheaper, faster and more accurate than ever before. ●Made of rust-resistant stainless steel. ●High-precision measurements can be made as it is supported by the tapered section. Applications: ●For measuring center-to-center distances between threaded holes and locating the positions of threaded holes. Specifications: ●Nominal dimensions (mm): M5 x 0.8 ●Nominal dimensions: M5 x P0.8 ●Measuring section diameter (mm): 7 ●Total length (mm): 11 ●Measuring section length (mm): 6 ●Runout between measuring section and threaded section (mm): 0.01 or less ●Measurement section accuracy (mm): ±0.005 or less Material/Finish: ●Body: Stainless steel
