SUGATSUNE (110021888) AUH-900 Panel Hanging Bracket AUH-900 1 piece

Catalogue number: AUH-900 Features: ●Long snap-in hanging bracket allows easy installation and removal of panels without the use of tools. ●When installed, the gap between the panel and the wall is just 5mm or less. ●The panel and wall sides are made of the same material, making handling, including maintenance, easy. ●Easy installation of consecutive panels. ●Effective in preventing warping of large panels. ●Screw guide grooves (see drawing) can be set in the mounting holes. Uses: ●Display panels, paintings, furniture, etc. Specifications: ●Color: Silver ●Suspension load (kgf): 30 ●Load capacity (N/kgf): 294.2/30 ●Width (mm): 43 ●Depth (mm): 4.3 ●Height (mm): 43 ●Length (mm): 900 ●Thickness (mm): 4.3 ●A (mm): 900 ●Number of mounting holes (pcs): 2 ●Surface treatment: Silver anodized ●Load capacity (N): 294.2 ●Load capacity (kgf): 30 ●Silver anodized Material/Finish: ●Aluminum alloy Caution: ●Both the panel and the wall must be installed in a position where there is a solid base such as a pillar behind them. ●The load capacity is 900 mm high for this product (A dimension 700 mm) with two poles (780 mm apart) at the top and bottom. ●The value is for a panel 700 mm wide and 25 mm thick (load is at the center of the thickness). ●Please note that this will vary depending on the distance between the wall and the load and the panel material.
