Catalog number: NF-47D-GR Features: ●The soft closing mechanism allows the hook to close slowly and automatically. ●The hook has a handle at the tip, making it easy to open. ●The hook is designed to have little protrusion when stored. ●The polycarbonate used is flame-retardant grade (UL94V-0 compliant). Applications: ●Cabinets, vehicles, etc. Specifications: ●Color: Gray ●Suspension load (N/kgf): 75/7.6 ●Load capacity (N/kgf): 75/7.6 ●Width (mm): 23.9 ●Depth (mm): 17.4 ●Height (mm): 54.4 ●A (mm): 15 ●B (mm): 47 ●D (mm): 17.4 ●H (mm): 54.4 ●H1 (mm): 54.4 ●L1 (mm): 54.4 ●W (mm): 23.9 ●Number of mounting holes (pcs): 1 ●Flame retardant performance is equivalent to UL94HB. Material/Finish: ●Polycarbonate (PC) Note: ●A bracket (NF-47DB) sold separately is required for mounting to metal.
