SUGATSUNE (110044905) AUH-C70 / Catch metal fitting AUH-C70 1 piece

Catalog number: AUH-C70 Features: ●Catch for AUH type panel hanging bracket. ●The function of holding the panel makes it difficult for the panel to fall even if it is shifted left or right or pushed up from below. ●Just align it with the AUH type to easily adjust the position. Specifications: ●Hanging load (N/kgf): 100/10.2 ●Hanging load (kgf): 10.2 ●Width (mm): 70 ●Height (mm): 47 ●Thickness (mm): 4.3 ●Number of mounting holes (pcs): 2 ●Holding force (N): 50 ●Holding force (kgf): 5.1 ●Load capacity (N): 100 ●Load capacity (kgf): 10.2 ●Surface finish: Barrel polishing ●Barrel polishing Material/Finish: ●Stainless steel (SUS304) Caution: ●When using alone without using with AUH type, make sure that it is not pulled toward you. ●We recommend using two on the left and right for each panel. ●The holding power of the catch varies. ●Please check the actual product. ●The image is of one of the products in the same series, and the appearance may differ from that of the product number here.
