Catalog number: HG-S50-12 Features: ●The HG-S-MN, HG-S-21, and HG-S-75 models, which are different sizes, have been added, making it possible to use it in a wider range of applications. ●It can rotate freely 360°. ●Wiring can be passed through the center hole (excluding the HG-S-MN model). ●Five hole diameters are available: φ12, φ21.5, φ34, φ50, and φ75. Applications: ●Operation panels for machine tools, LCD monitors, etc. Specifications: ●Rated torque (N・m): 5 ●Hole diameter (mm): 12.0 ●Type: Horizontal installation ●External dimensions (mm): 54 ●Passed our company's 20,000-time opening and closing test Material/Finish: ●Stainless steel (SUS430) Caution: ●Can be used upside down ●However, the screws must be fixed from the mounting surface ●The product will not function if fixed from the opposite surface ●The image is of one of the products in the same series, and the appearance may differ from that of the product number here.
