Catalog number: SUG-31-405R-PD Features: ●Excellent abrasion resistance and shock absorption, it can rotate even on glass and metal fragments scattered on the floor. ●Ergonomic design with low starting resistance and rolling resistance. ●The rotating part uses a double ball bearing system that provides good rotation even under load. ●The material is extremely resistant to cutting chips and other debris. Uses: ●Heavy-duty transport equipment Specifications: ●Wheel diameter D (mm): 127 ●Type: Fixed type ●Allowable load (daN): 245 ●Allowable load (kgf): 250 ●Wheel width (mm): 51.6 ●Mounting height H (mm): 169.8 ●Mounting seat A (mm): 101.6 ●Mounting seat B (mm): 114.3 ●Mounting pitch X (mm): 76.2-92.1 ●Mounting pitch Y (mm): 66.7-76.2 ●Mounting hole diameter P (mm): 10.3 x 19.6 ●Allowable load (N): 2450 ●Plate type ●Fixed type ●Mounting hole diameter P: 10.3 x 19.6 mm Material/Finish: ●Metal fittings: Steel ●Metal fittings surface treatment: Glossy chromate treatment ●Wheels: Special chloroprene rubber (with steel wheel cover)
