Suiden Industrial Fan (Large Fan) Wall Mounted Aluminum Blade 50cm Safety Explosion-Proof SF-50D2-3A 1 Unit

Catalog number: SF-50D2-3A Features: ● A safe, explosion-proof wall-mounted type with a large air volume. Applications: ● For ventilation and air circulation in dangerous locations where an explosion-proof model is required. Specifications: ● Power supply (V): Three-phase 200 ● Explosion class and ignition level: eG3 ● Power consumption (W) (50/60Hz): 153/236 ● Blade diameter (cm): 50 ● Width (mm): 560 ● Depth (mm): 405 ● Height (mm): 630 ● Power cord length (m): 10 (without plug) ● Maximum air volume (［［M3］］/min) (50Hz): 270 ● Maximum air volume (［［M3］］/min) (60Hz): 310 ● Standard power consumption fee (50Hz): 2.1 yen/h ● Standard power consumption fee (60Hz): 3.2 yen/h ● Swing left and right (°): 87 ● Power cord length: 10m (without plug) ● Blades: 4 (made of aluminum) ● Swing angle: 87° ● Pressure-resistant explosion-proof structure with cable gland Material/Finish: ● Blades: Aluminum ● Legs: Iron Caution: ● May not be usable depending on environmental conditions. ● Be sure to use the product in a Class 2 hazardous location.
