TAIYO Quick Exhaust Valve QV2-10 1pc

Catalogue number: QV2-10 Features: ●Ideal for speeding up actuators. ●Excellent responsiveness. ●Large exhaust flow rate. ●Excellent durability. ●Maintenance can be performed with the piping in place. Specifications: ●Connection diameter: Rc3/8 ●Effective cross-sectional area (mm2): (IN-OUT) 47/(OUT-IN) 53 ●Fluid used: Air ●Operating pressure (MPa): 0.2-1 ●Total length (mm): 56 ●Operating temperature range (℃): 5-60 ●Effective cross-sectional area (mm2) (IN-OUT): 47 ●Effective cross-sectional area (mm2) (OUT-EXH): 53 ●Fluid temperature: 5-60℃ ●Operating pressure: 0.2-1MPa
