TAIYO Lubricator (with bracket) EAL3-10-B 1 piece

Catalog number: EAL3-10-B Features: ● Mixes an appropriate amount of lubricant into the air, smoothing the movement of pneumatic equipment and preventing friction. ● Set after the regulator. Specifications: ● Operating pressure (MPa): 1 ● Processing air flow rate (m3/min): 0.5 ● Oil storage capacity (cm3): 65 ● Connection port size: Rc3/8 ● Overall length (mm): 177 ● Overall width (mm): 68 ● Fluid used: Air ● Minimum oil drip flow rate (L/min): 60 ● Operating temperature range: -5 to +60°C (but do not freeze) ● Minimum oil drip flow rate (L/min): 60 ● Recommended lubricant: Turbine oil type 1 (additive-free) ISOVG32 equivalent ● Fluid used: Air Set contents/accessories: ● Bracket
