Catalog number: SRV3-08-BD Features: ●Adjusts air to a stable pressure. Specifications: ●Set pressure (MPa): 0.05 to 0.85 ●Operating pressure (MPa): 1 ●Connection diameter: Rc1/4 ●Total length (mm): 82 ●Total width (mm): 45 ●Operating fluid: Air ●Fluid temperature (℃): 5 to 60 ●Pressure gauge: D type ●Operating temperature range: -5 to +60℃ (but do not freeze) Set contents/accessories: ●Bracket ●D-type pressure gauge Note: ●The D-type pressure gauge will be shipped not assembled to the main unit.
