TAIYOH KL Combination MKL2-20 1 S

Catalogue number: MKL2-20 Features: ●Compact combination of filter, regulator and lubricator for cleaning air, adjusting pressure and supplying lubricating oil to pneumatic equipment. Specifications: ●Filtration accuracy (μm): 5 ●Operating pressure (MPa): 0.93 ●Processing air flow rate (［［M3］］/min): 2.0 ●Connection port size: Rc3/4 ●Oil storage capacity (［［CM3］］): 160 ●Total length (mm): 248 ●Total width (mm): 172 ●Set pressure (MPa): 0.05-0.83 ●Fluid used: Air ●Fluid temperature (℃): 5-60 ●Drain discharge method: With manual discharge valve ●Oil used: Type 1 turbine oil (equivalent to ISO VG#32) ●With pressure gauge and bracket
