TERADA Small sewage-mixed water submersible pump, automatic, 60Hz, SXA-150, 1 unit

Catalogue number: SXA-150 Features: ●Uses an oil bath system for the mechanical seal. ●Equipped with a built-in motor protection device. Applications: ●For construction and civil engineering. ●For industrial equipment. ●For building equipment. Specifications: ●Discharge volume (L/min): 100 ●Total head (m): 3.5 ●Frequency (Hz): 60 ●Caliber (mm): 40 ●Power supply (V): Single-phase 100 ●Current (A): 3.2 ●Output (kW): 0.15 ●Total width (mm): 212 ●Total length (mm): 154 ●Total height (mm): 328 ●Power cord length (m): 4 ●Power cord length: 4m ●Foreign object passage diameter: 20mm or less ●Automatic operation type Materials/Finish: ●Casing: Synthetic resin (with glass fiber) ●Impeller: Synthetic resin (with glass fiber) ●Main shaft: SUS420J2
