TRIENS 100V Cord Reel 1.25 x 3 cores x 10m Orange SCS-310B-OR 1 unit

Catalogue number: SCS-310B-OR Features: * Grounded three-outlet cord reel. * Uses a mounting base that is easy to attach and detach. * Equipped with a swivel function as needed. * Equipped with an automatic reset thermoswitch. * Earthquake-resistant cable with excellent durability. * Can be used for both hanging and wall mounting. Applications: * For supplying 100V power. * Various assembly lines, maintenance factories, etc. * Improved working environment. Specifications: ● Wire type: SVCT ● Wire length (m): 10 ● Wire thickness (mm2): 1.25 ● Number of cores (C): 3 ● Outlet shape: 3P x 2 with grounding, 2P x 1 ● Number of outlets: 3 ● Rated voltage (V): 125 ● Rated current (A): 6 ● Width (mm): 164 ● Depth (mm): 290 ● Height (mm): 314 ● Color: Orange ● Outlet specifications: 12A/125V ● Rated voltage: 125V ● Rated current: 6A ● Total cord length (m): 10 ● Total primary cord length (m): 0.8 ● Wire thickness/number of cores: 1.25sq x 3C ● Main unit dimensions (mm): 314 x 290 x 164 ● Main unit weight (kg): 4.1 Material/Finish: ● Cable: Vinyl cabtyre cable ● Main unit cover: Resin Set contents/Accessories: ● Complete mounting base Caution: ●When using, be sure to pull out all cables.
