TRUSCO α Pressed Rubber Caster Fixed Φ150 TK-150C 1 pc

Catalog number: TK-150C Features: *The swivel section uses double bearings to achieve smooth rotation. *The wheel rotation section uses radial bearings for excellent durability. *The steel wheel has a distinctive star shape with a good design. Uses: ● For mounting on transport carts, etc. Specifications: ● Wheel diameter D (mm): 150 ● Type: Fixed type ● Allowable load (daN): 161 ● Allowable load (kgf): 164 ● Wheel width (mm): 45 ● Mounting height H (mm): 198 ● Mounting seat A (mm): 138 ● Mounting seat B (mm): 92 ● Mounting pitch X (mm): 100-112 ● Mounting pitch Y (mm): 53-56 ● Mounting hole diameter P (mm): 11.0 ● Compatible models: SH-22S, SH-1WS ● Mounting seat (mm): 138 x 92 ● Mounting pitch (mm): 100-112 x 53-56 ● Wheel material: Rubber ● Caster diameter (mm): 150 ● Plate type ● Fixed type ● With radial bearing Material/Finish: ● Metal fittings: Steel ● Metal fittings surface treatment: Unichrome plating finish ● Wheels: Steel wheels, rubber
