TRUSCO α Pressed Rubber Caster with Swivel Double Stopper Φ100 TJB-100C 1 pc

Catalog number: TJB-100C Features: *The swivel section uses double bearings to achieve smooth rotation. *The wheel rotation section uses radial bearings for excellent durability. *The steel wheel has a distinctive star shape with a good design. Uses: ● For mounting on transport carts, etc. Specifications: ● Wheel diameter D (mm): 100 ● Type: Free-wheeling (with double stoppers) ● Allowable load (daN): 80 ● Allowable load (kgf): 82 ● Wheel width (mm): 35 ● Mounting height H (mm): 144 ● Mounting seat A (mm): 95 ● Mounting seat B (mm): 95 ● Mounting pitch X (mm): 67-74 ● Mounting pitch Y (mm): 67-74 ● Mounting hole diameter P (mm): 10.5 ● Compatible models: SH-32S ● Allowable load (N): 800 ● Plate thickness (mm): 4.0 ● Plate type ● Radial bearing included ● Free-wheeling (with double stoppers) ● Locks the swivel part and wheels simultaneously Materials/Finish: ● Metal fittings: Steel ● Metal fittings surface treatment: Unichrome plating finish ● Wheels: Steel wheels, rubber
