TRUSCO α Pressed Rubber Caster with Swivel Double Stopper Φ150 TJB-150C 1 pc

Catalog number: TJB-150C Features: *The swivel section uses double bearings to achieve smooth rotation. *The wheel rotation section uses radial bearings for excellent durability. *The steel wheel has a distinctive star shape with a good design. Uses: ● For mounting on transport carts, etc. Specifications: ● Wheel diameter D (mm): 150 ● Type: Free-wheeling (with double stoppers) ● Allowable load (daN): 161 ● Allowable load (kgf): 164 ● Wheel width (mm): 45 ● Mounting height H (mm): 198 ● Mounting seat A (mm): 120 ● Mounting seat B (mm): 120 ● Mounting pitch X (mm): 75-90 ● Mounting pitch Y (mm): 75-90 ● Mounting hole diameter P (mm): 11.0 ● Compatible models: SH-22S, SH-1WS ● Caster diameter (mm): 150 ● Mounting seat (mm): 120 x 120 ● Mounting pitch (mm): 75-90 x 75-90 ● Wheel material: Rubber ● Plate thickness (mm): 4.0 ● Plate type ● Radial bearing included ● Free-wheeling (with double stoppers) ● Locks the swivel and wheels at the same time Material/Finish: Metal fittings: Steel; Metal fitting surface treatment: Unichrome plating; Wheels: Steel wheels, rubber
