TRUSCO α Pressed Rubber Caster, Swivel, Φ100, TJ-100C, 1 pc

Catalogue number: TJ-100C Features: ● The swivel section uses double bearings to ensure smooth rotation. ● The wheel rotation section has radial bearings and is highly durable. ● The steel wheels have a distinctive star shape that is well designed. Applications: ● For mounting on transport carts, etc. Specifications: ● Wheel diameter D (mm): 100 ● Type: Swivel ● Allowable load (daN): 80 ● Allowable load (kgf): 82 ● Wheel width (mm): 35 ● Mounting height H (mm): 144 ● Mounting seat A (mm): 95 ● Mounting seat B (mm): 95 ● Mounting pitch X (mm): 67-74 ● Mounting pitch Y (mm): 67-74 ● Mounting hole diameter P (mm): 10.5 ● Compatible models: SHT platform cart ● Plate type ● With radial bearings ● Swivel Material/Finish: ● Metal fittings: Steel ● Metal fittings surface treatment: Unichrome plating finish ● Wheels: Steel wheels, rubber
