TRUSCO α Pressed Rubber Caster, Swivel, Φ150, TJ-150C, 1 pc

Catalog number: TJ-150C Features: *The swivel section uses double bearings to achieve smooth rotation. *The wheel rotation section uses radial bearings for excellent durability. *The steel wheel has a distinctive star shape with a good design. Uses: ● For mounting on transport carts, etc. Specifications: ● Wheel diameter D (mm): 150 ● Type: Free-swivel ● Allowable load (daN): 161 ● Allowable load (kgf): 164 ● Wheel width (mm): 45 ● Mounting height H (mm): 198 ● Mounting seat A (mm): 120 ● Mounting seat B (mm): 120 ● Mounting pitch X (mm): 75-90 ● Mounting pitch Y (mm): 75-90 ● Mounting hole diameter P (mm): 11.0 ● Caster diameter (mm): 150 ● Mounting seat (mm): 120 x 120 ● Mounting pitch (mm): 75-90 x 75-90 ● Wheel material: Rubber ● Plate thickness (mm): 4.0 ● Plate type ● With radial bearing ● Free-swivel Material/Finish: ● Metal fittings: Steel ● Metal fittings surface treatment: Unichrome plating finish ● Wheels: Steel wheels, rubber
