TRUSCO Urethane Coil Hose 5.6m Orange UCH-7 1 pc

Catalog number: UCH-7 Features: ●Does not easily become bent and has excellent abrasion resistance. ●Excellent flexibility, elasticity, and stretchability. Also strong. ●Handle part is straight, so no hand hose is required. ●Coiled for a wide range of work. Specifications: ● Coil diameter (mm): 42 ● Color: Orange ● Hose inner diameter x outer diameter (mm): 5 x 8 ● Usage range (m): 5.6 ● Total length (mm): 1200 ● Coil length (mm): 600 ● Outer diameter (mm): 8 ● Inner diameter (mm): 5 ● Fluid used: Air ● Dimensions (mm) B: 500 ● Fluid temperature: -5 to 60 ° C ● Operating pressure: 0.8 MPa ● Hose inner diameter x outer diameter: 5 x 8 mm ● Connection fittings: R1/4 male thread, G1/4 female thread, G1/4 universal female thread ● With nipple ● Dimensions D (mm): 100 Material / Finish: ● Polyurethane Caution: ● Do not use in places where the connection fittings are subjected to impact or may get caught on something (such as floor steps or seams of checkered steel plates). It may cause unexpected accidents such as "connection fittings flying out". ● When separating the connection fittings, hold the fittings with your hand. ●After connecting the connecting fittings, gently pull them from both sides to make sure they do not come loose. ●When connecting the fittings, first tighten them by hand as far as they will go, and then use a tool to tighten them another 1/4 turn (90°) to 1/2 turn (180°).
