TRUSCO Crimp Nut Flat Head Stainless Steel Plate Thickness 2.5 M5 x 0.8 100 Pieces TBN-5M25SS-C 1 Box

Catalog number: TBN-5M25SS-C Features: ●Can be installed quickly and easily even in places where hands cannot reach. ●Can be installed on thin plates and plywood where welding and tapping are not possible. ●Can be installed firmly and reliably without damaging the base material. Applications: ●Housing-related: sashes, curtain walls, gates, fences, kitchen equipment, steel furniture, etc. ●Automobiles and vehicles-related: buses, trucks, container cars, automobiles, railway cars, etc. ●Home appliances-related: refrigerators, microwaves, washing machines, etc. Specifications: ●Crimping plate thickness (mm): 1.5 to 2.5 ●Pilot hole diameter (mm): 7.1 ●Compatible screws: M5 x 0.8 ●Nut outer diameter (mm): 7 ●Total length (mm): 12.5 ●Flange thickness (mm): 1 ●Number of pieces per pack: 100 ●Head shape: flat head ●Flat head ●Boxed Material/Finish: ●Stainless steel (SUS303)
