Catalog number: SCT-1040BT Features: ● Internal cone hammering type, so there is little variation in construction. ● Construction completion can be confirmed by using the dedicated hand holder. ● Made of stainless steel, it is ideal for construction locations where corrosion resistance is required. Specifications: ● Thread size: M10 ● Outer diameter (mm): 12.5 ● Total length (mm): 40 ● Thread length (mm): 16 ● Drill diameter (mm): 13.0 ● Maximum tensile load (kN): 15.6 ● Packed Material/Finish: ● Stainless steel (SUS304 series) Note: ● Maximum tensile load is the value when the concrete strength Fc = 21N/[[MM2]].
