Catalog number: SCT-1660BT Features: ● Internal cone hammering type, so there is little variation in construction. ● Construction completion can be confirmed by using the dedicated hand holder. ● Made of stainless steel, it is ideal for construction locations where corrosion resistance is required. Specifications: ● Thread size: M16 ● Outer diameter (mm): 20.0 ● Total length (mm): 60 ● Thread length (mm): 23 ● Drill diameter (mm): 20.5 ● Maximum tensile load (kN): 35.7 ● Packed Material/Finish: ● Stainless steel (SUS304 series) Note: ● Maximum tensile load is the value when the concrete strength Fc = 21N/[[MM2]].
